The AG6601 is a universal hardware platform with universal image support for Windows 7 Embedded (WES7), Windows Embedded Standard (WES), Windows CE 6, or Linux out of the box. Citrix, Microsoft, VMWare, Quest and CLI TermPro Terminal Emulation clients are all standard, as is Internet Explorer. In addition, CLI?s Device Manager software is included with each device, making simple and powerful management a reality. The AG6601 combines strong power, performance and flexibility while maintaining efficient power consumption. If you are looking for an Ethernet "Dumb Terminal" with a Parallel Port, the AG6601 can be configured to act as a "Dumb Ethernet Terminal" just like the ET2000. They can be configured to automatically boot up to a 5250 or 3270 sign-on screen. You can see this in the CLI YouTube Video "5250 Autostart MT2301" at the link directly below: https://www.youtube.com/watch?feature=player_detailpage&v=x8u3ZL4DG5s This video applies to all CLI
CE.NET based Thin Client Terminals with CE4, CE5 or
CE6 Operating Systems. Featured Highlights
Click here for more information on the CLI AG6601 Thin ClientTerminal ProductivityUser productivity is enhanced by eliminating any learning curve and costs associated with PC products. Centralized management of individual units better utilizes support and help desk assets. Cost SavingsEliminates 5x94 remote controllers by using an inexpensive network router. You can also eliminate your SNA WAN and use TCP/IP thereby reducing communication costs. Plus, no per seat license cost. As with all of CLI's Thin client Terminals and Modular Twinax Display Stations, you select from a wide array of keyboard and monitor styles for individual application or user requirements. Click here for more information on the CLI AG6601 Thin ClientTerminal For Complete Specifications
Download the
CLI
AG6601 Datasheet
|
Model |
AG6601W |
AG6601H |
AG6601L |
Operating System |
WES7 |
CE6 |
Linux |
Processor |
AMD G-Series T48E - 1.4 GHz |
||
Memory (min/max) |
2gb / 4gb |
1gb / 2gb |
1gb / 4gb |
Flash (Storage) (min/max) |
4gb / 16gb |
1gb / 8gb |
1gb / 4gb |
Network |
Auto sense 10/100/1000
BaseT twisted pair Ethernet, RJ
45 connector, Wake On LAN |
||
Wireless |
Model AG6661W |
Wireless CE5 and
CE6 Units |
Model AG6661L |
I/O Ports |
1 Parallel Port, 1 Serial Port (DB9 RS 232C), 4 USB 2.0 Ports, 2 PS/2 Ports (one for Keyboard, one for Mouse), 1 Mic-in jack, 1 Audio Out Jack, 1 RJ45 Ethernet |
||
Video |
VX855-based Chrome9 HCM 3D graphics core |
||
Audio |
Full 16 bit stereo FM synthesis, stereo line out, 8 bit mini microphone line in |
||
Physical Specifications |
Dimensions: 1.4 in / 3.5cm (W) x 5.6 in / 14.2cm (D) x
8 in / 20.5cm (H) |
||
Environment |
Operating temperature: 0° C to 40° C (32° F to 104° F), Storage temperature: 40° C to 60° C ( 41° F to 140° F) Relative humidity: 20% to 80% non condensing Power requirements: 100 240 VAC, 50/60 Hz Convection cooling, no fan |
||
Regulatory Compliance |
FCC Class B ROHS CE Mark UL, T |
For Complete Specifications Download the
CLI
AG6601 Datasheet
Model |
AG6601W |
AG6601H |
AG6601L |
Operating System |
WES7 |
CE6 |
Linux |
Protocols |
Microsoft RD .x ICA X Client VNC (Remote PXE, Provision Networks VMware View Web Browser |
Microsoft RD .x ICA X Client
VNC (Remote PXE, Provision Networks VMware View Web Browser |
RDP 5 compatible ICA X Client
VNC (Remote PXE, Provision Networks VMware View Web Browser |
Terminal Emulations |
IBM TN5250e, TN3270e, 3151 |
||
Web Browser |
Internet Explorer 7
|
Windows CE Internet Explorer 7 Web |
Firefox 2, including pop popup blocker,
|
Email Client |
Via local browser or Outlook Express |
Via local browser |
Via local browser |
Other Features |
Thin Print available via download Supports optional Castles Technology EZ100 smart card reader via USB or serial Special builds available via download (i.e. Kiosk, .Net, IE7 and others) VNC Elo and Microtouch touch screen support Thin Print Integrated 802.11 b/g wireless XDMC VNC |
||
Enhanced printing |
Windows X printer User installable LPD/LPR
|
AS400/iSeries /5250,
Compatibility with
Universal printer
SerialD w/ network |
AS400/iSeries/5250,
Compatibility with
Universal printer
LPD client and host
Network (TCP/IP) |
Security |
Multiple levels of security including user lock-out and multiple built-in user Shell environments |
||
Remote Configuration
/ |
DHCP ,
SNMP, FTP, |
DHCP , SNMP , FTP
CLI
SNMP |
DHCP , SNMP , FTP
CLI
SNMP |
Server Operating System Compatibility
/ Support |
Microsoft Windows Server 2016, 2012, 2008, 2003, 2000, Windows NT 4.0, Terminal Server Edition; Terminal Services
Citrix Application Delivery Infrastructure including XenApp and
Virtual Desktop Infrastructure (VDI) support: vmware VDM*, Provision UNIX, Linux, IBM OS/400, i5/OS, OS/390, z/OS
Microsoft Windows Server 2008, 2003, 2000, Windows NT 4.0, Terminal
Citrix Application Delivery Infrastructure including XenApp and
Virtual Desktop Infrastructure (VDI) support: vmware VDM*, Provision |
||
Languages |
English (US), Spanish (MX), Italian, French, Canadian French, Chinese, Austrian / German, Scandinavian, Spanish, Japanese / Kana, Korean |
||
Network File Transfer Protocols |
TCP / and UDP , all XP supported protocols PXE |
90-Day Twin Data Warranty on AG6601 / MT1500 / MT2300
/ MT3500 / All ST Series
Logic Modules
1-Year Return-to-Depot Warranty on NEW 122-Key Keyboards
3-Year Acer Warranty on NEW LED Monitors
Form ID 45837
